Abstract

Background: Personal Identification with the help of radiographic examination of Skull is a potentially useful method in cases where fragments of skull persist with no likelihood of identification. Frontal sinus Nasal bone, piriform aperture and Nasal septum show racial and geographical variations and their shape can be used as one of the classic indicators of sexual dimorphism. The purpose of this study was to evaluate and classify the variations in the pattern of frontal sinus and nasal septum, the dimensions, size and the shape of the piriform aperture and their sexual dimorphism.

Material and methods: Postero-anterior cephalometric radiograph of 180 healthy individuals aged 20-70 years were traced for the morphology of frontal sinus and piriform aperture, pattern of nasal bone, nasal septum pattern using various classification systems. Results: The most predominant pattern of frontal sinus seen in the study sample was the left dominant asymmetry 56.1% and the least predominant was symmetry 3.9%. The mean height of frontal sinus on right side in males was greater than in females and was statistically significant. The most predominant pattern of nasal bone was Type A (56.7%) and least predominant was Type C 2.8%. The most predominant pattern of nasal septum in males and females was found to be straight 62.2% and 63.3% respectively and rare type 1.1%. The proportions of pattern of nasal septum were not statistically different among males and females. The mean height and mean area of the piriform aperture was found to be greater in males as compared to females which was statistically significant (p < 0.05).

Conclusion: The frontal sinus, nasal bone, nasal septum and piriform aperture can be useful aids for forensic identification.

• 1.   Nikam S, Gadgil R. Personal identification in forensic science using uniqueness of radiographic image of frontal sinus. J Forensic Odontostomatol. 2015;33(1):1–7.
• 2.   Kavitha B, Einstein A, Sivapathasundharam B, et al. Limitations in forensic odontology. J Forensic Dent Sci. 2009;1(1):8–10.
• 3.   David MP, Saxena R. Use of frontal sinus and nasal septum patterns as an aid in personal identification: A digital radiographic pilot Study. J Forensic Dent Sci. 2010;2(2):77–80.
• 4.   Kumar R, Athota A, Rastogi T, et al. Forensic radiology: An emerging tool in identification. J Indian Acad Oral Med Radiol. 2015;27(3):416–22.
• 5.   Goyal M, Naikmasur VG. Are frontal sinuses useful indicators of sex? J Forensic Leg Med. 2013;20(2):91–4.
• 6.   Kumar AP, Doggalli N, Patil K. Frontal sinus as a tool in identification. Int J Forensic Odontol. 2018;3(2):55–8.
• 7.   Porbonikova S. An X-Ray investigation of the development of the frontal sinus in children. Folia Med. 1974;16(4):213–20.
• 8.   Nambiar P, Naidu MD, Subramanian K. Anatomical variability of the frontal sinuses and its applications on forensic identification. Clin Anat. 1999;12(1):16–9.
• 9.   Reddy S, Rajesh N, Raghavendra MN, et al. Unleash the Unknown: Frontal Sinus and Nasal Septal Patterns in Personal Identification. Int J Dent Sci Res. 2014;2(6):141–5.
• 10.   Shrestha O, Bhattacharya S, Jha N, et al. Cranio facial anthropometric measurements among Rai and Limbu community of Sunsari District, Nepal. Nepal Med Coll J. 2009;11(3):183–5.
• 11.   Camargo JR, Daruge E, Prado FB, et al. The Frontal sinus morphology in radiographs of Brazilian subjects: Its Forensic importance. Braz J Morphol Sci. 2007;24(4):239–43.
• 12.   Taniguchi M, Sakoda S, Kano T, et al. Possible use of nasal septum and frontal sinus patterns to Radiographic Identification of Unknown Human remains. Osaka City Med J. 2003;49(1):31–8.
• 13.   Hwang TS, Song J, Yoon H, et al. Morphometry of the nasal bones and piriform apertures in Koreans. Ann Anat. 2005;187(4):411–4.
• 14.   Rehani S, Chandrashekhar C, Radhakrishnan R. The role of radiography in forensic dental practice. Indian J Dent Adv. 2011;3(1):413–7.
• 15.   McLaughlin RB Jr, Rehl RM, Lanza DC. Clinically relevant frontal sinus anatomy and physiology. Otolaryngol Clin North Am. 2001;34(1):1–22.
• 16.   Tatlisumak E, Ovali GY, Asirdizer M, et al. CT study on morphometry of frontal sinus. Clin Anat. 2008;21(4):287–93.
• 17.   Verma P, Verma KG, Khosa R, et al. Combined use of frontal sinus and nasal septum patterns as an aid in forensics: A digital radiographic study. North Am J Med Sci. 2015;7(2):47–52.
• 18.   Soman B, Sujatha GP, Lingappa A. Morphometric evaluation of the frontal sinus in relation to age and gender in subjects residing in Davangere, Karnataka. J Forensic Dent Sci. 2016;8(1):57.
• 19.   Yoshino M, Miyasaka S, Sato H, et al. Classification system of frontal sinus pattern by radiography. Its application to identification of unknown skeletal remains. Forensic Sci Int. 1987;34(4):289–99.
• 20.   Schuller A. A note on the identification of skull X-Ray pictures of the frontal sinus. Med J Aust. 1943;25(1):554–6.
• 21.   Fatu C, Puisoru M, Rotaru M, et al. Morphometric evaluation of the frontal sinus in relation to age. Ann Anat. 2006;188(3):275–80.
• 22.   Ponde JM, Ralmundo Nonato A, Jose Maldonado V, et al. Anatomical variations of the frontal sinus. Int J Morphol. 2008;26(4):803–8.
• 23.   Aydinlioglu A, Kavakli A, Erdem S. Absence of frontal sinus in Turkish individuals. Yonsei Med J. 2003;44(2):215–8.
• 24.   Asherson N. Identification by Frontal Sinus Prints: A Forensic Medical Pilot Survey. London: Lewis and Co.; 1965.
• 25.   Talaiepour AR, Sazgar AA, Bagheri A. Anatomic variations of the paranasal sinuses on CT scan images. J Dent (Tehran). 2005;2(4):142–6.
• 26.   Naser AZ, Boroujeni MP. CBCT Evaluation of Bony Nasal Pyramid Dimensions in Iranian Population: A Comparative Study with Ethnic Groups. Int Sch Res Notices. 2014;2014:819378.
• 27.   Asghar A, Dixit A. Morphometric Study of nasal Bone and piriform Aperture in Human Dry Skull of Indian Origin. J Clin Diagn Res. 2016;10(1):AC05–AC07.
• 28.   Prado FB, Caldas RA, Rossi AC, et al. Piriform aperture morphometry and nasal bones morphology in Brazilian population by posteroanterior Caldwell radiography. Int J Morphol. 2011;29(2):393–8.
• 29.   Hommerich CP, Riegel A. Measuring of the piriform aperture in humans with 3D SSD-CT reconstructions. Ann Anat. 2002;184(5):455–9.
• 30.   Hwang TS, Kang HS. Morphometry of nasal bones and nostrils in Koreans. Ann Anat. 2003;185(2):189–93.
• 31.   Ofodile FA. Nasal bones and pyriform apertures in blacks. Ann Plast Surg. 1994;32(1):21–6.
• 32.   Lang J, Baumeister R. Uber das postnatale Wachstum der Nasenhöhle. Gegenbaurs Morphol Jahrb. 1982;128(3):354–93.
• 33.   Karadag D, Ozdol NC, Beriat K, et al. CT evaluation of the bony nasal pyramid dimensions in Anatolian people. Dentomaxillofac Radiol. 2011;40(3):160–4.
• 34.   Wolpoff MH. Climatic influence on the skeletal nasal aperture. Am J Phys Anthropol. 1968;29(3):405–23.
• 35.   Boyan N, Kizilkanat E, Tekdemir I, et al. Usefulness of Nasal Morphology in Surgical Approaches for Skull Base Tumours. Neurosurg Q. 2007;17(4):283–6.
