Abstract

Summary: The objective of this study is to describe the variations in liver shape and the characteristics of the main liver sulci in adult Senegalese subjects. Material and method: We collected 51 livers from adult Senegalese subjects of both sexes. For each specimen, we identified the shape and sulci on the different surfaces. This allowed us to determine whether the right and left ventro-dorsal sulci were complete or incomplete, and to look for the presence of a hepatic bridge in cases of incomplete sulci on the visceral surface. Results: We observed a predominance of the ovoid shape of the liver (57% of cases), diaphragmatic grooves which were rare but present (9.3% of cases) and a ventrodorsal groove mostly complete on the left (63% of cases) than on the right (13.2% of cases). However, the incomplete segments of the right and left ventro-dorsal sulci were filled by a bridge of hepatic tissue which constituted the paracave portion of the caudate lobe on the right in 93.79% of cases. On the left, the absence of the umbilical ligament in 9.8% of cases resulted in complete fusion of the quadrate lobe with the left lobe. The presence of accessory grooves on the visceral surface was noted in 69% of cases, as well as an accessory lobe located between the venous ligament and the umbilical ligament. Conclusion: This work has highlighted numerous morphological variations of the liver in people of African descent in Senegal. Knowledge of these variations is essential for the surgical management of particularly malignant liver diseases.

• 1.   Lanchou G, Montagne M, Pellet L. A propos des sillons de la face convexe du foie Bull Ass Anat 1965, 126 : 947-958.
• 2.   Fraser CG. “Accessory lobes of the liver,”Annals of Surgery 1952, 135 (1) : 127–129.
• 3.   Gueye ML, Diop B, Ghada Z, Touré AO, Seck M et al. Hepatectomies for hepatocellular carcinoma: indications and results of a prospective serie at ALDH/Senegal HPB 2024, 26 : 211-212.
• 4.   Macchi V, Porzionato A, Parenti A, De Caro R. Main and accessory liver sulci: an anatomical and radiological study. Surgical and Radiologic Anatomy. 2021;43(5):715-724.
• 5.   Couinaud C. Le foie, études anatomiques et chirurgicales Masson, Paris, 1957: 223-247.
• 6.   Netter FH. Atlas of human anatomy. 2nd ed. New York : Guilford press. 2000
• 7.   Leguerrier A. N.D.A. Editions scientifiques et juridiques,Paris, 1993, 127-131.
• 8.   Castaing D, Veilhan L A. Anatomie du foie et des voies biliaires. EMC (Elsevier Masson SAS, Paris), Hépatologie, 7- 001-A-10, 2008. 39.
• 9.   Drake R L, Vogl. W, Mitchell A W M. Gray’s anatomie, abdomen, foie. Elsevier Masson SAS, 2006, 296-299.
• 10.   Hasan M, Gani A. Variations in hepatic morphology and its surgical importance. Anatomy & Cell Biology. 2021;54(4):450-458.
• 11.   Chevalier J M. Anatomie, le tronc 1ere édition, Médecine Science Flammarion, Paris, 1998, 212-225.
• 12.   Rouvière H, Delmas A. Anatomie humaine tome II 4e édition, Masson, Paris, 1997, 432-459.
• 13.   Aktan Z.A, Savas R, Pinar Y, Arslan O. Lobe And Segment Anomalies Of the Liver J Anat. Soc. India 2001, 50(1) 15-16.
• 14.   Chin J, O’Toole P, Lin J, Velavan Hepatic morphology: variations and its clinical importance Eur. J. Anat. 22 (3) : 195-201 (2018).
• 15.   Macchi V, Feltrin G, Parenti A, De Caro R. Diaphragmatic sulci and portal fissures J Anat 2003, Vol 202(3):303-8.27 Indian Journal of Anatomy / Volume 15, Issue 1 / January – April 2026 16. Othman M, Sherif H. The prevalence of diaphragmatic sulci of the liver in the African population: A radiological review. African Journal of Medicine. 2024;53(1):12-19.
• 17.   Sharmila A. Morphological study of anomalies of lobes and segments of human liver Int J Pharm Bio Sci 2016 Oct ; 7(4) : (B) 810 – 815.
• 18.   Sinha A, Kumar V, Singh P. Morphological variations of liver sulci and their clinical implications: A CT-based study. Journal of Clinical and Diagnostic Research. 2023;17(2):AC01-AC05.
• 19.   Saxena A, Agarwal KK, Jakhwal C, Singh S, Das AR Some Variable Facts of Liver: Embryological and Clinical Perspective International Journal of Anatomy, Radiology and Surgery, 2016 Jan, Vol 5(1) 64-67.
• 20.   Patil S, Sethi M, Kaka S. Morphological study of human liver and its surgical importance Int J Anat Res 2014, Vol 2(2) :310-14. ISSN 2321- 4287.
• 21.   Nayak S. Accessory fissures and lobes of the liver: A cadaveric study with clinical significance. International Journal of Morphology. 2022;40(3):612-618.
